Plan.a™ Low Profile Aluminium Entrance Matting with Needlepunch Carpet

Defend against dirt and moisture with versatile aluminium entrance matting

Plan.a is a high-end entrance matting product and is also COBA Flooring’s best-selling solution. Offering excellent product performance along with options for design customisation, Plan.a can be tailored to suit an array of building styles and entrance configurations. Comprised of an aluminium rail system linked with flexible joints, it offers the utmost durability for busy buildings. Genuinely handmade to order in the UK, providing reassurance of precision and quality. The low-profile version of Plan.a is suited to entrances that feature a shallower matwell or for projects with lower footfall or looking to reduce material costs. Needlepunch inserts are available in charcoal and grey to be sympathetic to most commercial entrance designs, and offers a less expensive carpet surface that still provides effective cleaning action.

Request a Sample

Features and Benefits

Technical Specification

Styles and Colours

Accessories

Downloads and Resources

Technical Drawings

plan-a-low-open-aluminium-mattting-needlepunch-grey

plan-a-low-open-aluminium-mattting-needlepunch-charcoal

plan-a-low-open-aluminium-mattting-anodized-needlepunch-grey

plan-a-low-open-aluminium-mattting-anodized-needlepunch-charcoal

plan-a-low-closed-aluminium-mattting-needlepunch-charcoal

plan-a-low-closed-aluminium-mattting-anodized-needlepunch-grey

plan-a-low-closed-aluminium-mattting-anodized-needlepunch-charcoal

Plan.a Low Closed - Bronze & Needlepunch - Charcoal

Features and Benefits

Robust, high-quality aluminium system for heavy-duty use designed to cope with high footfall.
Flexible, yet durable PVC linking joints for ease of handling and easy fitting.
Custom-made to order to your specification.
Choose from one, or a combination of different surface options.
Also now available with vibrant coloured needlepunch or needlefelt polypropylene carpet inserts as used our Logomat Precision products.
Logomats can be incorporated into any Plan.a design.
Manufactured in the UK.
Fire tested to BS EN 13501-1 and slip tested to BS 7976-2.

Technical Specification

Uniclass: Pr_35_57_11_26 Entrance mats

CAWS: N10 / 300 Entrance Matting

Material: Aluminium rails, PVC connection strips, PP Carpet Inlays

Surface Finish: Carpet

Product Height: 10 mm

Durability: Heavy to very heavy traffic entrances

Environmental Resistance: Suitable for dry environments

UV Resistance: Yes

Typical Applications: Entrance areas

Installation Method: Installed into recessed well or laid to surface

Other Product Performance Information: Uniform floor load = 14.36 KN/ m². Wheel load 159 kg per wheel

Fire Tested to: BS EN 13501-1 Class Efl – s2

COO (Country of Origin): UK

Notes: Slip resistance specifications are based on the correct direction of travel i.e. perpendicular to the rails and inserts. Black Anodised finish availability is subject to quantity required.

Slip Tested to: BS 7976-2 – low slip potential
